= pÉêîáÅÉ=j~åì~ä=pmUMc^=L=pmUMc_= m~ÖÉ=NM=ENUF=
=
Position SP80FA-4x6-2 SP80FA-2x13-2 SP80FA-2x17-2 SP80FA-2x32-2
L1 2x3m7H8A-LAB 2x3m7H8A-LAB 2x3m7H8A-LAB 2x4m7H16A-LAB
L2 2x3m7H8A-LAB 2x3m7H8A-LAB 2x3m7H8A-LAB 2x4m7H16A-LAB
Q4 TIP132 TIP132 IRF730 IRF730
R5 47R9W5%17MSO5 47R9W5%17MSO5 47R9W5%17MSO5 47R9W5%17MSO5
R8 4K7.7W1% 8K2.7W1% 27K.7W1%SO5 27K.7W1%SO5
R9 1M.7W1% 150K.25W5% 180K.7W1% 180K.7W1%
R14 2R22W5%2MST 2R22W5%2MST - -
R15 2R22W5%2MST 2R22W5%2MST - -
s~êá~åí=ëéÉÅáÑáÅ=ÅçãéçåÉåíë=Ñçê=NNRs=îÉêëáçåë=J=êÉî=MS=
Position SP80FA-4x6-2U SP80FA-2x13-2U SP80FA-2x17-2U SP80FA-2x32-2U
C2 2n2Y10 2n2Y10 2n2Y10 2n2Y10
C3 2n2Y10 2n2Y10 2n2Y10 2n2Y10
C5 2n2Y10 2n2Y10 2n2Y10 2n2Y10
C6 2n2Y10 2n2Y10 2n2Y10 2n2Y10
C8A - - - -
C8B 1500u200V35x504TSI 1500u200V35x504TSI 1500u200V35x504TSI -
C8C - - - 2200u200V35x55
C9A - - - -
C9B 1500u200V35x504TSI 1500u200V35x504TSI 1500u200V35x504TSI -
C9C - - - 2200u200V35x55
C12 3900u100V30x45 3900u100V30x45 1800u160V30x50 1800u160V30x50
C13 3900u100V30x45 3900u100V30x45 1800u160V30x50 1800u160V30x50
C14 3900u100V30x45 3900u100V30x45 1800u160V30x50 1800u160V30x50
C15 3900u100V30x45 3900u100V30x45 1800u160V30x50 1800u160V30x50
C18 4n7400VMFKT5 4n7400VMFKT5 - -
C19 4n7400VMFKT5 4n7400VMFKT5 - -
C21 - - 680p400VK20005%5 680p400VK20005%5
D7 - - 15V.4W5% 15V.4W5%
D8 - - 39V.4W2% 39V.4W2%
FU1 T20AH250-6.3x32 T20AH250-6.3x32 T20AH250-6.3x32 T30AH125-6.3x32
JMPR
230V
- - - -
JMPR 1
115V
R02M.8 R02M.8 R02M.8 R02M.8
JMPR 2
115V R02M.8 R02M.8 R02M.8 R02M.8
JMPR
СP1-СP3 R03M.8 R03M.8 R03M.8 R03M.8
JMPR
СP2-СP4 AWG16BLU300VVW1 AWG16BLU300VVW1 AWG16BLU300VVW1 AWG16BLU300VVW1
JMPR
СP5-СP6 - - - -
L1 2x4m7H16A-LAB 2x4m7H16A-LAB 2x4m7H16A-LAB 2x2mH32A-LAB
L2 2x4m7H16A-LAB 2x4m7H16A-LAB 2x4m7H16A-LAB 2x2mH32A-LAB
Q4 TIP132 TIP132 IRF730 IRF730
R5 22R9W5%17MSO5 22R9W5%17MSO5 22R9W5%17MSO5 22R9W5%17MSO5
R8 4K7.7W1% 8K2.7W1% 27K.7W1%SO5 27K.7W1%SO5
R9 1M.7W1% 150K.25W5% 180K.7W1% 180K.7W1%
R14 2R22W5%2MST 2R22W5%2MST - -
R15 2R22W5%2MST 2R22W5%2MST - -
