Lab.gruppen fp2400Q User Manual

= pÉêîáÅÉ=j~åì~ä=fkQ= m~ÖÉ=Q=ERF=
=
`çãéçåÉåí=äáëí=Ñçê=fkQ=J=êÉî=MP=
- Safety critical component. Should only be replaced with the specified type.
Position Partnumber Description Comment Side
C1 100n63VMMK5 Capacitor polyester 100n 63V MMK 5mm Top
C2 22p200VNP05%5 Capacitor ceramic 22p 200V NP0 5% 5mm Top
C3 22p200VNP05%5 Capacitor ceramic 22p 200V NP0 5% 5mm Top
C4 22u50V Capacitor electrolytic 22u 50V 5mm Top
C5 22u50V Capacitor electrolytic 22u 50V 5mm Top
C101 100n63VMMK5 Capacitor polyester 100n 63V MMK 5mm Top
C102 22p200VNP05%5 Capacitor ceramic 22p 200V NP0 5% 5mm Top
C103 22p200VNP05%5 Capacitor ceramic 22p 200V NP0 5% 5mm Top
C104 22u50V Capacitor electrolytic 22u 50V 5mm Top
C105 22u50V Capacitor electrolytic 22u 50V 5mm Top
C201 100n63VMMK5 Capacitor polyester 100n 63V MMK 5mm Top
C202 22p200VNP05%5 Capacitor ceramic 22p 200V NP0 5% 5mm Top
C203 22p200VNP05%5 Capacitor ceramic 22p 200V NP0 5% 5mm Top
C204 22u50V Capacitor electrolytic 22u 50V 5mm Top
C205 22u50V Capacitor electrolytic 22u 50V 5mm Top
C301 100n63VMMK5 Capacitor polyester 100n 63V MMK 5mm Top
C302 22p200VNP05%5 Capacitor ceramic 22p 200V NP0 5% 5mm Top
C303 22p200VNP05%5 Capacitor ceramic 22p 200V NP0 5% 5mm Top
C304 22u50V Capacitor electrolytic 22u 50V 5mm Top
C305 22u50V Capacitor electrolytic 22u 50V 5mm Top
C401 22u50V Capacitor electrolytic 22u 50V 5mm Top
C402 22u50V Capacitor electrolytic 22u 50V 5mm Top
C405 100n50VY5W5%5 Capacitor ceramic 100n 50V Y5W 5% 5mm Top
C406 100n50VY5W5%5 Capacitor ceramic 100n 50V Y5W 5% 5mm Top
D401 Variant dependent, see separate list Top
D402 1N5404 Diode power 1N5404 Top
D403 1N5404 Diode power 1N5404 Top
D404 1N4148 Diode signal 1N4148 Top
D405 18V1.3W5% Diode zener 18V 1.3W 5% Top
D406 1N4148 Diode signal 1N4148 Top
D407 18V1.3W5% Diode zener 18V 1.3W 5% Top
L1 L2xBEAD2M Inductor bead double 2 modules Top
L2 L2xBEAD2M Inductor bead double 2 modules Top
L101 L2xBEAD2M Inductor bead double 2 modules Top
L102 L2xBEAD2M Inductor bead double 2 modules Top
L201 L2xBEAD2M Inductor bead double 2 modules Top
L202 L2xBEAD2M Inductor bead double 2 modules Top
L301 L2xBEAD2M Inductor bead double 2 modules Top
L302 L2xBEAD2M Inductor bead double 2 modules Top
P1 NCJ6FI-H_NEU Connector XLR/J 3pole female+jack 90dg NEUTRIK NCJ6FI-H Top
P101 NCJ6FI-H_NEU Connector XLR/J 3pole female+jack 90dg NEUTRIK NCJ6FI-H Top
P201 NCJ6FI-H_NEU Connector XLR/J 3pole female+jack 90dg NEUTRIK NCJ6FI-H Top
P301 NCJ6FI-H_NEU Connector XLR/J 3pole female+jack 90dg NEUTRIK NCJ6FI-H Top
Q401 MPSA42 Transistor bipolar signal MPSA42 Top
Q402 MPSA92 Transistor bipolar signal MPSA92 Top
R1 10K.7W1% Resistor Metal Film 10K.7W1% Top
R2 Variant dependent, see separate list Top
R3 10K.7W1% Resistor Metal Film 10K.7W1% Top
R4 Variant dependent, see separate list Top
R5 47R.25W5% Resistor Carbon Film 47R.25W5% Top
R101 10K.7W1% Resistor Metal Film 10K.7W1% Top
R102 Variant dependent, see separate list Top
