Page #20 background image
= pÉêîáÅÉ=j~åì~ä=fkQ= m~ÖÉ=R=ERF=
=
Position Partnumber Description Comment Side
R103 10K.7W1% Resistor Metal Film 10K.7W1% Top
R104 Variant dependent, see separate list Top
R105 47R.25W5% Resistor Carbon Film 47R.25W5% Top
R201 10K.7W1% Resistor Metal Film 10K.7W1% Top
R202 Variant dependent, see separate list Top
R203 10K.7W1% Resistor Metal Film 10K.7W1% Top
R204 Variant dependent, see separate list Top
R205 47R.25W5% Resistor Carbon Film 47R.25W5% Top
R301 10K.7W1% Resistor Metal Film 10K.7W1% Top
R302 Variant dependent, see separate list Top
R303 10K.7W1% Resistor Metal Film 10K.7W1% Top
R304 Variant dependent, see separate list Top
R305 47R.25W5% Resistor Carbon Film 47R.25W5% Top
R402 470R.7W1% Resistor Metal Film 470R.7W1% Top
R405 18K.7W1% Resistor Metal Film 18K.7W1% Top
R406 1K.7W1% Resistor Metal Film 1K.7W1% Top
R408 18K.7W1% Resistor Metal Film 18K.7W1% Top
R409 10R.25W5% Resistor Carbon Film 10R.25W5% Top
R410 1K.7W1% Resistor Metal Film 1K.7W1% Top
R411 4K73W5% Resistor metal film 4K7 3W 5% Top
R412 4K73W5% Resistor metal film 4K7 3W 5% Top
S401 Variant dependent, see separate list Top
S402 SPPJ32F29A_ALP Switch inter locking PCB DPDT ALPS SPPJ32F29A Top
S403 SPPJ32F29A_ALP Switch inter locking PCB DPDT ALPS SPPJ32F29A Top
S404 SPPJ32F29A_ALP Switch inter locking PCB DPDT ALPS SPPJ32F29A Top
U401 LF353 IC Operational amplifier LF353 Top
U402 LF353 IC Operational amplifier LF353 Top
s~êá~åí=ëéÉÅáÑáÅ=ÅçãéçåÉåíë=
Position IN4-C IN4-CM IN4-C-29DB
D401 - LREDD3_EVE -
R2 15K4.7W1% 15K4.7W1% 11K.7W1%
R4 15K4.7W1% 15K4.7W1% 11K.7W1%
R102 15K4.7W1% 15K4.7W1% 11K.7W1%
R104 15K4.7W1% 15K4.7W1% 11K.7W1%
R202 15K4.7W1% 15K4.7W1% 11K.7W1%
R204 15K4.7W1% 15K4.7W1% 11K.7W1%
R302 15K4.7W1% 15K4.7W1% 11K.7W1%
R304 15K4.7W1% 15K4.7W1% 11K.7W1%
S401 - SPPJ32F29A_ALP -
aÉëÅêáéíáçå=Ñçê=î~êá~åí=ÇÉéÉåÇÉåí=ÅçãéçåÉåíë=
Partnumber Description
11K.7W1% Resistor Metal Film 11K.7W1%
15K4.7W1% Resistor Metal Film 15K4.7W1%
LREDD3_EVE Diode LED Red D3 lying EVERLIGHT A264B
SPPJ32F29A_ALP Switch inter locking PCB DPDT ALPS SPPJ32F29A
