Lab.gruppen fp2400Q User Manual

= pÉêîáÅÉ=j~åì~ä=pmUMc^=L=pmUMc_= m~ÖÉ=V=ENUF=
=
Position Partnumber Description Comment Side
R6 33R.25W5% Resistor Carbon Film 33R.25W5% Top
R7 2R21W5% Resistor metal film 2R2 1W 5% Top
R8 Variant dependent, see separate list May have different
value
Top
R9 Variant dependent, see separate list May have different
value
Top
R10 39K.7W1% Resistor Metal Film 39K.7W1% May have different
value
Top
R11 18K.7W1% Resistor Metal Film 18K.7W1% May have different
value
Top
R12 4K7.7W1% Resistor Metal Film 4K7.7W1% May have different
value
Top
R13 4R7.25W5% Resistor Carbon Film 4R7.25W5% Top
R14 Variant dependent, see separate list Top
R15 Variant dependent, see separate list Top
R16 - Not used May have different
value
Top
RE1 PCSPNO40A18V Relay PCB SPNO 40A 18V May have different
value
Top
s~êá~åí=ëéÉÅáÑáÅ=ÅçãéçåÉåíë=Ñçê=OPMs=îÉêëáçåë=J=êÉî=MS=
Position SP80FA-4x6-2 SP80FA-2x13-2 SP80FA-2x17-2 SP80FA-2x32-2
C2 1n5Y10 1n5Y10 1n5Y10 1n5Y10
C3 1n5Y10 1n5Y10 1n5Y10 1n5Y10
C5 1n5Y10 1n5Y10 1n5Y10 1n5Y10
C6 1n5Y10 1n5Y10 1n5Y10 1n5Y10
C8A 220u385V35x55PW 220u385V35x55PW 220u385V35x55PW -
C8B - - - 1500u200V35x504TSI
C8C - - - -
C9A 220u385V35x55PW 220u385V35x55PW 220u385V35x55PW -
C9B - - - 1500u200V35x504TSI
C9C - - - -
C12 3900u100V30x45 3900u100V30x45 1800u160V30x50 1800u160V30x50
C13 3900u100V30x45 3900u100V30x45 1800u160V30x50 1800u160V30x50
C14 3900u100V30x45 3900u100V30x45 1800u160V30x50 1800u160V30x50
C15 3900u100V30x45 3900u100V30x45 1800u160V30x50 1800u160V30x50
C18 4n7400VMFKT5 4n7400VMFKT5 - -
C19 4n7400VMFKT5 4n7400VMFKT5 - -
C21 - - 680p400VK20005%5 680p400VK20005%5
D7 - - 15V.4W5% 15V.4W5%
D8 - - 39V.4W2% 39V.4W2%
FU1 T10AH250-5x20 T10AH250-5x20 T10AH250-5x20 T15AH250-6.3x32
JMPR
230V
R02M.8 R02M.8 R02M.8 R02M.8
JMPR 1
115V
- - - -
JMPR 2
115V - - - -
JMPR
СP1-СP3 - - - R03M.8
JMPR
СP2-СP4 - - - AWG16BLU300VVW1
JMPR
СP5-СP6 R02M.8 R02M.8 R02M.8 -
