pé~êÉé~êí=äáëí=Ñçê=ÑmOQMMn=
Completed modules
Partnumber Description
A04B-6-2 Amplifier 400W class B, variant 6-2
IN4-CM 4 channel input amplifier, variant CM
LD54-4x6-2 Led display 5 x led 4 channel, variant 4x6-2
OUT4CHAB-A04B 4 channel output connector board channel AB, variant A04B
OUT4CHCD-A04B 2 channel output connector board channel CD, variant A04B
SP80FA-4x6-2 Switch mode powersupply 8kW flyback board A, variant 4x6-2, 230V
SP80FA-4x6-2U Switch mode powersupply 8kW flyback board A, variant 4x6-2U, 115V
SP80FB-4x6-2 Switch mode powersupply 8kW flyback board B, variant 4x6-2, 230V
SP80FB-4x6-2U Switch mode powersupply 8kW flyback board B, variant 4x6-2U, 115V
Mecanical parts
- Safety critical component. Should only be replaced with the specified type.
Partnumber Description
TCA04BA-PBLK Top / bottom cover
FP-FP2400Q Front panel
SPLA04BA-A Side panel left
SPRA04BA-A Side panel right
RP-FP2400Q Rear panel 230V
RP-FP2400QU Rear panel 115V
HDL2HEM5_MEN Handle
DCSL1-PBLK Dustfilter clip left
DCSR1-PBLK Dustfilter clip right
DF139x62x5-20
Dustfilter left
DF115x62x5-20
Dustfilter right
KNBD11.1_TAI Gain potentiometer knob
Screws
Partnumber Description
MRX3x10SV Machine screw, pan head, phillips, M3x10, black
MFX3x12SV Machine screw, countersunk head, phillips, M3x12, black
MFX3x20SV Machine screw, countersunk head, phillips, M3x20, black
RTS-HST2.9x9.5SV Self tapping screw, pan head, torx, 2.9x9.5mm, black
MC6S4x10FBB-SV Hexagon socket screw, cap head, M4x10 with spring washer, black
LAB_T3x8-SV Top / bottom cover screw, torx, M3x8, black
