Lab.gruppen fp2400Q User Manual

= pÉêîáÅÉ=j~åì~ä=pmUMc^=L=pmUMc_= m~ÖÉ=NR=ENUF=
=
Position Partnumber Description Comment Side
R43 R04M.6 Resistor jumper 0R 4modules D.6mm Top
R44 Variant dependent, see separate list Top
R45 Variant dependent, see separate list Top
R46 Variant dependent, see separate list Top
R47 Variant dependent, see separate list Top
R48 Variant dependent, see separate list Top
S1 TP1-0-5A3x8x21 Thermal protector Single Pole Single Trough on - off 5A
3x8x21mm
Bot.
U1 UC3851 IC PWM UC3851 Top
U2A Variant dependent, see separate list May have different
value
Top
U2B Variant dependent, see separate list Top
VR1 VR10KLY2X3M Trimpotentiometer 10K lying 2x3modules Top
VR2 VR22KLY2X3M Trimpotentiometer 22K lying 2x3modules Top
VR3 VR10KLY2X3M Trimpotentiometer 10K lying 2x3modules Top
VR4 15K.7W1% Resistor Metal Film 15K.7W1% Top
s~êá~åí=ëéÉÅáÑáÅ=ÅçãéçåÉåíë=Ñçê=OPMs=îÉêëáçåë=J=êÉî=MN^=
Position SP80FB-4x6-2 SP80FB-2x11-2 SP80FB-2x13-2 SP80FB-2x17-2 SP80FB-2x32-2
C01 - - - - 100n400VMMK15
C1A 220u385V35x55PW 220u385V35x55PW 220u385V35x55PW 220u385V35x55PW -
C1B - - - -
1500u200V35x504
TSI
C1C - - - - -
C2A 220u385V35x55PW 220u385V35x55PW 220u385V35x55PW 220u385V35x55PW -
C2B - - - -
1500u200V35x504
TSI
C2C - - - - -
C6 - - - - 1n1250VMKP15
C21 1n5Y10 1n5Y10 1n5Y10 1n5Y10 1n5Y10
C22 1n5Y10 1n5Y10 1n5Y10 1n5Y10 1n5Y10
C24 - - - - 22n1000VMKP22.5
C25 - - - - 22n1000VMKP22.5
C27 100p1600VFKP15 100p1600VFKP15 100p1600VFKP15 100p1600VFKP15 -
D01 - - - - 1N4148
D2 - - - - STTA1512PILY
D15 43V.4W2% 43V.4W2% 39V.4W2% 43V.4W2% 43V.4W2%
D16 - - - - BYM26E
D17 - - - - 1N4148
L1 - - - - 400uHEFD30_LAB
LD01 - - - - LYEL2.5x5LY
LD02 - - - - LGRN2.5x5LY
Q9 R01M.6 (b-c) - R01M.6 (b-c) - BC557B
Q10 - - - - BC547B
R01 - - - - 4K7.7W1%
R1 18K9W5%17MSO5 18K9W5%17MSO5 18K9W5%17MSO5 18K9W5%17MSO5 33K9W5%17MSO5
R2 18K9W5%17MSO5 18K9W5%17MSO5 18K9W5%17MSO5 18K9W5%17MSO5 -
R3 18K9W5%17MSO5 18K9W5%17MSO5 18K9W5%17MSO5 18K9W5%17MSO5 -
R5 - - - - 330R2W5%SO5
R9 1K52W5%SO5 1K52W5%SO5 1K52W5%SO5 1K52W5%SO5 1K3W5%SO5
R19 5K62.7W1% 5K62.7W1% 5K62.7W1% 5K62.7W1% 5K9.7W1%
R23 8K2.7W1% 6K8.7W1% 6K8.7W1% 6K8.7W1% 6K8.7W1%
