= pÉêîáÅÉ=j~åì~ä=pmUMc^=L=pmUMc_= m~ÖÉ=NQ=ENUF=
=
Position Partnumber Description Comment Side
Q2 SGW25N120LY Transistor IGBT power SGW25N120 lying May have different
value
Bot.
Q3 SGW25N120LY Transistor IGBT power SGW25N120 lying May have different
value
Bot.
Q4 BC327 Transistor bipolar signal BC327 Top
Q5 TIP50 Transistor bipolar power TIP50 Top
Q6 BC547B Transistor bipolar signal BC547B Top
Q7 R01M.6 (b-e) Resistor jumper 0R 1module D.6mm Top
Q8 BC557B Transistor bipolar signal BC557B Top
Q9 Variant dependent, see separate list Top
Q10 Variant dependent, see separate list Top
R01 Variant dependent, see separate list Top
R1 Variant dependent, see separate list Top
R1A - Not used Top
R2 Variant dependent, see separate list Top
R3 Variant dependent, see separate list Top
R3A - Not used Top
R5 Variant dependent, see separate list Top
R6 R104W10%SO5 Resistor wirewound R10 4W 10% 5mm stand off Top
R7 R104W10%SO5 Resistor wirewound R10 4W 10% 5mm stand off Top
R8 R104W10%SO5 Resistor wirewound R10 4W 10% 5mm stand off Top
R9 Variant dependent, see separate list Top
R10 4K77W5%10MSO5 Resistor wirewound 4K7 7W 5% 10modules 5mm stand
off
Top
R11 680K.25W5% Resistor Carbon Film 680K.25W5% Top
R12 33K.7W1% Resistor Metal Film 33K.7W1% Top
R13 270K.7W1% Resistor Metal Film 270K.7W1% Top
R14 10K.7W1% Resistor Metal Film 10K.7W1% Top
R15 18K.7W1% Resistor Metal Film 18K.7W1% Top
R16 180R.7W1% Resistor Metal Film 180R.7W1% Top
R17 120K2W5%SO5 Resistor metal film 120K 2W 5% 5mm stand off Top
R18 10K.7W1% Resistor Metal Film 10K.7W1% Top
R19 Variant dependent, see separate list Top
R20 432K1W1% Resistor Metal Film 432K 1W 1% Top
R21 750K.7W1% Resistor Metal Film 750K.7W1% Top
R22 4R7.25W5% Resistor Carbon Film 4R7.25W5% Top
R23 Variant dependent, see separate list Top
R24 4R7.25W5% Resistor Carbon Film 4R7.25W5% Top
R25 15K.7W1% Resistor Metal Film 15K.7W1% Top
R26 1K.7W1% Resistor Metal Film 1K.7W1% Top
R27 Variant dependent, see separate list Top
R28 82R.25W5% Resistor Carbon Film 82R.25W5% Top
R29 4M7.25W5% Resistor Carbon Film 4M7.25W5% Top
R30 Variant dependent, see separate list Top
R31 220K.7W1% Resistor Metal Film 220K.7W1% Top
R32 Variant dependent, see separate list Top
R33 Variant dependent, see separate list Top
R34 Variant dependent, see separate list Top
R35 Variant dependent, see separate list Top
R36 15K.7W1% Resistor Metal Film 15K.7W1% Top
R37 Variant dependent, see separate list Top
R38 Variant dependent, see separate list Top
R39 Variant dependent, see separate list Top
R40 Variant dependent, see separate list Top
R41 18K.7W1% Resistor Metal Film 18K.7W1% Top
R42 - Not used Top
