= pÉêîáÅÉ=j~åì~ä=pmUMc^=L=pmUMc_= m~ÖÉ=NP=ENUF=
=
`çãéçåÉåí=äáëí=Ñçê=mfkaI=pmUMc_=J=êÉî=MN^=
- Safety critical component. Should only be replaced with the specified type.
Position Partnumber Description Comment Side
C01 Variant dependent, see separate list Top
C1A Variant dependent, see separate list Top
C1B Variant dependent, see separate list Top
C1C Variant dependent, see separate list Top
C2A Variant dependent, see separate list Top
C2B Variant dependent, see separate list Top
C2C Variant dependent, see separate list Top
C5 u68X27.5 Capacitor 680n X2 metallized propylene 27.5mm Top
C6 Variant dependent, see separate list Top
C7 10u63V6x10A Capacitor electrolytic 10u 63V 6x10mm axial Top
C9 10u50V Capacitor electrolytic 10u 50V 5mm Top
C10 22u50V Capacitor electrolytic 22u 50V 5mm Top
C11 470p200VNP05%5 Capacitor ceramic 470p 200V NP0 5% 5mm Top
C12 1n250VMMK5 Capacitor polyester 1n 250V MMK 5mm Top
C14 10n250VMMK5 Capacitor polyester 10n 250V MMK 5mm Top
C15 330p200VNP05%5 Capacitor ceramic 330p 200V NP0 5% 5mm Top
C16 330p200VNP05%5 Capacitor ceramic 330p 200V NP0 5% 5mm Top
C17 - Not used Top
C18 1n250VMMK5 Capacitor polyester 1n 250V MMK 5mm Top
C19 10u50V Capacitor electrolytic 10u 50V 5mm Top
C20 - Not used Top
C21 Variant dependent, see separate list Top
C22 Variant dependent, see separate list Top
C23 1n250VMMK5 Capacitor polyester 1n 250V MMK 5mm Top
C24 Variant dependent, see separate list Top
C25 Variant dependent, see separate list Top
C26 1n250VMMK5 Capacitor polyester 1n 250V MMK 5mm Top
C27 Variant dependent, see separate list Top
D01 Variant dependent, see separate list Top
D1 BYT12PI1000LY Diode power BYT12PI1000 lying Bot.
D2 Variant dependent, see separate list Bot.
D3 15V1.3W5% Diode zener 15V 1.3W 5% Top
D4 5V6.4W2% Diode zener 5V6 .4W 2% Top
D5 1N4148 Diode signal 1N4148 Top
D6 BYV26C Diode power switch BYV26C Top
D7 1N4004 Diode power 1N4004 Top
D8 1N4148 Diode signal 1N4148 Top
D9 1N4148 Diode signal 1N4148 Top
D10 1N4148 Diode signal 1N4148 Top
D11 BYV26C Diode power switch BYV26C Top
D12 BZW06P15B Diode transient voltage suppression BZW06P15B Top
D13 BAT85 Diode signal BAT85 Top
D14 1N4148 Diode signal 1N4148 Top
D15 Variant dependent, see separate list Top
D16 Variant dependent, see separate list Top
D17 Variant dependent, see separate list Top
L1 Variant dependent, see separate list Top
LD01 Variant dependent, see separate list Top
LD02 Variant dependent, see separate list Top
Q1 - Not used May have different
value
Bot.
