Label ETERNA 150 User Manual

46
PARAMETERS
EXPLANATION
P21
Internal Radar and Start enabling time when the Night Lock work program is selected
Time during which the Internal Radar and Start inputs remain enabled to open the door after the Night Lock work program has been set.
At 0% the function is disabled, at minimum value 01% = 10 seconds, at maximum value 100% = 120 seconds.
P22
Potentiometer ON
if function
F27= ON
Time after which the interlock between two automatic doors gets disabled if the open door doesn't close back
See para. "Interlock system". At the default value 0%, the function is disabled.
Time after which the interlock is disabled automatically if the door that is open does not close due to the high ow of people. In this case, if the
radar inside the second door is activated by the persons in the space between the two doors, the second door opens allowing the outow of
people.
At 01% the interlock disabling time and the ensuing second door opening time will be 10 seconds.
At 50% the interlock disabling time will be 60 seconds, at 100% the interlock disabling time will be 120 seconds.
P23
Pharmacy opening distance
Increasing the value will increase the pharmacy reduced opening value; min. setting 5cm./leaf, max. 20cm./leaf.
P24
Push & go function
Manually moving the leaf by a few centimetres in the opening direction activates an automatic opening cycle.
At 0% the function is disabled, at minimum value 01% = start of the opening after a displacement of 1 cm,
at maximum value 100% = 10 cm
P25
Holding tension with door closed
Adjustment of the motor holding voltage when the door is closed, to keep the leaves against the ledge.
Increasing the value increases the thrust exerted by the leaf on the closing ledge.
P26
ANTI‑ROLL FUNCTION FOR BOATS
At value 0% : FUNCTION OFF.
At value 01% : FUNCTION ON. See para. "Special functions with double electric lock → Anti-roll function for boats"
P27 Not used
P28 Not used
P29
Gong activation time to signal door crossing.
Adjustment of the duration of gong buzzer activation as a person crosses the automatic door. Time adjustable between 0.5 e 2 seconds.
P30 Not used
P31 Not used
P32 Not used
P33 Not used
P34
Potentiometer ON
if function
F73= ON
It allows you to adjust the time within which the user can issue the lock command from the inside once the door has closed.
If the value is "0" time is innite, so the lock command can always be issued from the internal touch button.
Values ranging between "1" and "100" will set a time ranging between 1 and 100 seconds (factory setting = 10 seconds).
Once this time has expired, if the electromagnet is not locked, activating the touch button causes the door to open.
P35
Potentiometer ON
if function
F73= ON
It allows you to set the time after which the electromagnet is automatically released after the door has been locked from the inside.
If the value is "0" (factory setting) time is innite, so the electromagnet remains locked until the user activates the inside button to leave. Values
ranging between "1" and "100" will set a time ranging between 1 and 100 minutes.
Once this time has expired the signalling light ashes, alternately switching between red and green, to warn the user that within 3 minutes the
door will be unlocked.
P36 Not used
P37 Not used
P38 Not used
P39 Not used
P40 Not used
P41 Not used
P42 Not used
P43 Not used
P44 Not used
P45 Not used
P46 Not used
P47 Not used
