Operation
CoaDATA 501 – Operators Manual 2.1 Page 17
Enter a calibration curve
1st conversion
curve
• Select 1. conversion and press Enter to confirm selection.
< curve >
A 9-point calibration curve can be entered with this menu.
Calibration curve points that are not to be used must have the entry 0.0 s.
For information of interpolation refer to chapter 5.5 Mathematics. The
system requires two points to be defined but we would recommend a
minimum of 3 points. You can exit the calibration curve menu with Esc if no
entry has been made. Once an entry has been made, all additional
calibration curve points must be retrieved and verified.
• Press Enter to type in the first calibration point. This point is defined as
point of greatest activity and shortest clotting time.
1.point
100.0 %
• Confirm the activity of 100.0 % by pressing Enter or overwrite the preset
entries by pressing the respective number keys. Confirm your entry with
Enter. The cursor switches to the time setting.
12.0 s
• Enter the clotting time for the respective activity of 100.0 %.
• Press Enter to confirm your entry.
The entry field for the next calibration curve point is displayed.
2.point
• Verify or update the second calibration curve point as described above.
• To enter additional calibration curve points follow the above instructions.
The following display appears once the last calibration curve point has been
confirmed:
<- select: ESC.
.. = work ENTER= more parameters
• Press Esc to access the measuring mode or Enter to add or verify
additional parameters.
