PL1220 Owner’s Manual
39
Do not worry about testing the laser for alignment at this point
as all other components need to be installed prior to testing.
6.4.1 Properly Installed Laser Tube
Figure 7-3 depicts the water tubes connected to the inlet water port. The cathode wire connects
to the pin with a set screw.
Figure 7-3: Cathode Side (Left)
To Next Page
