USER GUIDE
60
  GAS SYSTEM
Oven without grill (A type)
a) Hatch for door blocking.
b) Oven burner knob. To turn on press and turn
towards left.
c) Oven light switch.
Oven without grill (B type)
a) Oven burner knob. To turn on press and turn
towards left.
Oven without grill (C type)
a) Oven burner knob. To turn on press and turn
towards left.
Oven without grill (D type)
a) Oven burner knob. To turn on press and turn
towards left.
b) Ignition button.
c) Oven light switch.
Oven with grill
a) Oven burner knob.
b) Ignition button.
c) Oven light switch.
d) Heat protection plate.
d
c b
a
c
b
a
c
b
a
a
When using the grill, extract the heat protection
plate (d) and leave the oven door open.
WARNING
a
