USER GUIDE
78
  WASHROOM
16.4 Shower cab (Kosmo
Compact 5, Compact 9)
The Kosmo Compact 5 and Compact 9 models have
been provided with a system that allows them to have
a separated shower cabin according to the following
instructions:
Release the catch (a) (press to unlock) and rotate the
panel (b).
Release the catch (c) and rotate the panel (d).
16.5 Shower cab (Kosmo 509L,
512, 909L, 912)
During the journey, the shower door must be locked
by using the catch (a).
a
b
d
a
c
