LAIKA Kosmo Compact 5 - Lengthways Settee (Kosmo Series)

89
USER GUIDE
  SETTEES
18.3 Lengthways settee (Kosmo
series)
On the vehicles with lengthways settee (Kosmo
series), it is necessary to perform the operation
described below to obtain an additional passenger
seat.
Turn the panel (a) and the panel (b).
Fit the backrest (c) and secure it with the stop (d).
Position the cushions as shown in picture.
d
c
Left side of living area
The operation can be carried out both on the left
and the right settee.
NOTE
b
a
Left side of living area
h
g
e
f
Left side of living area
h
g
e
f
Left side of living area
Right side of living area
Direction of travel
