USER GUIDE
82
INTERNAL COMPONENTS
Manual handling of the bed
In case of malfunction or power failure, the bed
can be moved manually using the special handle (a)
supplied as standard equipment.
The handle must be inserted in to hole (b) located in
the cabinet under the bed surface, on the left side.
17.6.2 Bed above the dinette (Kosmo
series)
a) Bed up control.
b) Bed down control.
a
a
b
Control panel
c
When the bed is lowered using the electric
controls, make sure to unhook the latch (c) first,
otherwise the mechanism could be seriously
damaged.
WARNING
Before lowering the bed, position the cab seats so
that they do not interfere with bed movement.
WARNING
Make sure that children do not activate the bed
down/up control by themselves.
WARNING
When the vehicle is parked for a long time under
the sun, the bed must not remain in fully raised
position: leave a space of at least 10 cm between
the roof-light and the bed mattress.
WARNING
b
