SETTEES
18.2 Lengthways settee (Ecovip
DS series)
On the vehicles with lengthways settee (Ecovip DS
series), it is necessary to perform the operation
described below to obtain an additional passenger
seat.
Turn the panel (a) and the panel (b).
Fit the backrest (c) and secure it with the stop (d).
Position the cushions as shown in picture (2).
The operation can be carried out both on the left
and the right settee.
NOTE
c
b
a
Left side of living area
d
c
Left side of living area
f
e
Left side of living area
Picture 1
Picture 2
Left side of living area
Additional cushion
f
f
e
e
The additional cushion is not located between
the cushions in picture (1) but is supplied as an
additional piece to the vehicle upholstery.
NOTE
