LAIKA Kosmo Compact 5 - Kosmo Compact 9; Kosmo 509, 909

USER GUIDE
92
  NIGHT CONVERSION OPTIONAL
19.2 Kosmo Compact 9
To convert the dinette into a bed proceed as follows.
Lower the table.
Rotate the left cab seat.
Position the cushions as shown in picture.
19.3 Kosmo 509, 909
To convert the dinette into a bed proceed as follows.
Unhook the latch (a) and open the support (b) of the
additional panel (c).
Lower the table and fit the additional panel (c).
a
b
c
c
Additional cushions
