3.5 INPUT SETUP
3.5.1 Input Type
The Model 211 supports a variety of temperature sensors sold by Lake
Shore and other manufactures. An appropriate sensor type must be selected
for the input. Refer to Table 3-1 for a list of common sensor types. If a
particular sensor is not listed in the Input Type selection, look at Table 3-1
to find a sensor with similar range and excitation. For additional details on
sensors, refer to the Lake Shore Temperature Measurement and Control
Catalog or visit our website at www.lakeshore.com.
To select sensor type, press the Select key, use the s or t keys to select
―InPUt‖, then press the Enter key. Use the s or t keys to cycle through
the sensor types shown in Table 3-1. When the desired type appears, press
the Enter key. Proceed to Paragraph 3.5.2 to select a temperature curve or
press the Select key to return to the normal display.
Table 3-1. Sensor Input Types
* Refer to the Lake Shore Temperature Measurement and Control Catalog
for complete details on all Lake Shore Temperature Sensors.
