Lake Shore Model 211 User’s Manual
6-
2
Options & Accessories
6.3 WIRES
Common cryogenic wire available from Lake Shore. Other wire and
installation accessories are also available.
P/N
Cable Description
9001-005
Quad-Twist™ Cryogenic Wire. Two twisted pairs,
phosphor-bronze wire, 36 AWG, 0.127 mm (0.005 in)
diameter.
9001-006
Duo-Twist™ Cryogenic Wire. Single twisted pair,
phosphor-bronze wire, 36 AWG, 0.127 mm (0.005 in)
diameter.
9001-007
Quad-Lead™ Cryogenic Wire. Phosphor-bronze wire, flat,
32 AWG, 0.203 mm (0.008 in) diameter.
9001-008
Quad-Lead™ Cryogenic Wire. Phosphor-bronze wire, flat,
36 AWG, 0.127 mm (0.005 in) diameter.
6.4 SENSORS
Silicon diode sensors available from Lake Shore. Other sensors are also
available.
Sensor No.
Sensor Description
Series DT-420
The smallest silicon diode Temperature Sensor available. For
installation on flat surfaces. Sensor incorporates the same type
of silicon chip used in the Series DT-470 and DT-471.
Series DT-450
Silicon Diode Miniature Temperature Sensor. Same silicon
chip used in the DT-470 configured for installation in recesses
as small as 1.6 mm diameter by 3.2 mm deep.
Series DT-470
Silicon Diode Temperature Sensor. Interchangeable,
repeatable, accurate, wide range customized for cryogenics.
Series DT-471
An economical version of the DT-470 for applications where
temperature measurements below 10 K are not required.
Series DT-670
Lake Shore DT-670 diode temperature sensors offer the best
accuracy across the widest useful temperature range – 1.4 to
500 K – of any silicon diode sensor in the industry. Sensors
within the DT-670 series are interchangeable to the Curve
DT-670.
