Lakeshore 211 - Table A-2. Lake Shore DT-670 Silicon Diode

Lake Shore Model 211 User’s Manual
A-2 Curve Tables
Table A-2. Lake Shore DT-670 Silicon Diode
Break-
point
Temp.
(K)
Volts
Break-
point
Temp.
(K)
Volts
Break-
point
Temp.
(K)
Volts
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
500.0
491.0
479.5
461.5
425.5
390.0
346.0
320.0
298.5
279.0
261.0
244.0
228.0
213.0
198.5
184.5
171.5
159.5
148.0
137.5
127.5
118.0
109.0
100.5
93.5
0.090570
0.110239
0.136555
0.179181
0.265393
0.349522
0.452797
0.513393
0.563128
0.607845
0.648723
0.686936
0.722511
0.755487
0.786992
0.817025
0.844538
0.869583
0.893230
0.914469
0.934356
0.952903
0.970134
0.986073
0.998925
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
87.0
81.0
75.0
69.0
63.0
56.4
49.0
38.7
35.7
33.3
31.2
29.6
28.3
27.3
26.5
25.8
25.2
24.7
24.3
24.0
23.7
23.3
22.8
22.0
21.3
1.01064
1.02125
1.03167
1.04189
1.05192
1.06277
1.07472
1.09110
1.09602
1.10014
1.10393
1.10702
1.10974
1.11204
1.11414
1.11628
1.11853
1.12090
1.12340
1.12589
1.12913
1.13494
1.14495
1.16297
1.17651
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
20.2
17.10
15.90
14.90
14.00
13.15
12.35
11.55
10.75
10.00
9.25
8.50
7.75
6.80
5.46
4.56
4.04
3.58
3.18
2.62
2.26
1.98
1.74
1.53
1.40
1.19475
1.24208
1.26122
1.27811
1.29430
1.31070
1.32727
1.34506
1.36423
1.38361
1.40454
1.42732
1.45206
1.48578
1.53523
1.56684
1.58358
1.59690
1.60756
1.62125
1.62945
1.63516
1.63943
1.64261
1.64430
