Lake Shore Model 211 User’s Manual
Service 5-
13
5.6.4 Calibration Specific Interface Commands
ANALOG Analog Output Parameter Command
Input: ANALOG <mode>, <range>[term]
Format: n,n
<mode> Specifies analog output voltage mode, current
mode, voltage calibration mode, or current
calibration mode.
0 = Voltage mode
1 = Current mode
3 = Current calibration mode
4 = Voltage calibration mode
<range> Specifies analog output range. Valid entries are:
0 = 0 – 20 K or 0% output calibration mode
1 = 0 – 100 K or 50% output calibration mode
2 = 0 – 200 K or 100% output calibration mode
3 = 0 – 325 K
4 = 0 – 475 K
5 = 0 – 1000 K
Remarks: Allows manual setting of analog output values for
calibration purposes.
ANALOG? Analog Output Parameter Query
Input: ANALOG?[term]
Returned: <mode>, <range>[term]
Format: n,n (Refer to command for description)
