Lake Shore Model 211 User’s Manual
5-
14
Service
CALG Gain Calibration Constant Command
Input: CALG <input>, <type>, <value>[term]
Format: n,n,+n.nnnnn
<input> Specifies input or analog output the gain
calibration constant will be provided to. Valid
entries are 1 for input and 2 for the analog
output.
<type> Specifies the input sensor type. Valid entries are:
0 = Silicon Diode or Analog Output Voltage
Mode
1 = GaAlAs Diode or Analog Output Current
Mode
2 = 100 Plat/250
3 = 100 Plat/500
4 = 1000 Plat
5 = NTC RTD
<value> Gain calibration constant value.
Remarks: Provides the gain calibration constant for the selected input
or analog output.
CALG? Gain Calibration Constant Query
Input: CALG? <input>, <type>[term]
Returned: <mode>, <range>[term]
Format: n,n
<input> 1, or 2
<type> 0 – 5
Returned: <value>[term]
Format: +n.nnnnn (Refer to command for description.)
CALREAD? 6-Digit Input Reading Query
Input: CALREAD? [term]
Returned: <value>[term]
Format: ±nnnnnnn
Remarks: Returns 6-digit value of selected input reading. Used for
CALZ and CALG functions.
