6 Information for Mounting and Installation
6 Information for Mounting and Installation
6.1 Mounting - Basic Instructions
6.1.1 Safety
WARNING!
For the F200K version without mains frequency suppression, it is mandatory to mount it with
its viewing opening on the burner in such a way that it is protected against the detection of
mains frequency light. This mounting must meet the requirements of a tool mounting.
The LAMTEC mounting brackets FV30 and FV40 meet this requirement.
After attaching the union nut to the F200K /V, tighten the set screws located in this union nut
with an Allen key. This prevents unintentional disconnection of the connection.
Mounting in a cooler housing of the FS50, FS51 series also ensures tool mounting.
Advice on this is available from LAMTEC support.
Warning notice
The flame monitor without mains frequency suppression is provided with a warning: e. g.
WARNING!
WARNING!
The fiber optic flame detector versions F200K.. IR-.. FO with IR sensors may only be used with
the LAMTEC IR Fiber optic FOR...-IR or FOF...-IR.
6.1.2 UL Listed
In preparation
NOTICE
For applications within the scope of the UL Listed certification procedure, it must be ensured
that the components used are "Listed" certified. That is, in addition to the flame detector used
must also be the connection cable and if used the power supply "Listed" certified.
The applicable installation rules according to NFPA70 (NEC) must be observed.
WARNING After scanner commissioning tighten set screw
in scanner coupling nut!
Flame monitor without mains frequency suppression!
