I/O Mapping
Device: ABCC CompactCom 40 Connection: Exclusive Owner
Input: 19 INT (38 Bytes), Connection Point 100 Output: 2 INT (4 Bytes), Connection Point 150
 Generic EDS files are available for download at http://www.lasermech.com/fiberminiupdates
 Use FiberMINI
®
Monitor PC software to set IP configuration or node address before use.
WORD
TYPE
NAME
WEB ID
0
Input Data
Status Bits
2.0
1
Input Data
Active Faults
2.1
2
Input Data
Historical Faults
1
3
Input Data
Upper Assembly Temperature
2.2
4
Input Data
Lower Assembly Temperature
2.3
5
Input Data
Electronics Temperature
2.4
6
Input Data
HSU Voltage
2.5
7
Input Data
Actual Lens Position
2.6
8
Input Data
Target Lens Position
2.7
9
Input Data*
Upper Assembly Temp Limit
3.0/21.0
10
Input Data*
Lower Assembly Temp Limit
3.1/21.1
11
Input Data*
Electronics Temp Limit
3.2/21.2
12
Input Data*
Temp Difference Limit
3.3/21.3
13
Input Data*
Steps per mm
3.4/21.4
14
Input Data*
Control Options
3.5/21.5
15
Input Data*
Home Minimum
3.6/21.6
16
Input Data*
Home Maximum
3.7/21.7
17
Input Data*
Focus Position
3.8/21.8
18
Input Data
Maximum Position
3.9
0
Output Data
Command Bits
11
1
Output Data
Set Position (Remote)
13
N/A
Web Only
Set Position (Web)
22
N/A
Web Only
Head Firmware
94
N/A
Web Only
Head Revision
95
N/A
Web Only
Head Serial Number
96
N/A
Web Only
Controller Firmware
97
N/A
Web Only
Controller Revision
98
N/A
Web Only
Controller Serial Number
99
* Output Data also available using the Web Interface.
Sensor and limit values are displayed in the following units:
1. Temperature: °C x 10 (i.e. 300 = 30.0 °C), 999 = Sensor Error
2. Voltage: See HSU Voltage chart
3. Position: mm x 100 (i.e. 850 = 8.50 mm)
