3.2 EtherNet/IP / Modbus TCP / DeviceNet Module (If Equipped)
 The Industrial Network module is optional. If you purchased the optional module, it is pre-installed
in the controller.
 If you did not purchase the optional module, a blank plate is pre-installed in the controller.
There are (2) status LEDs located on the front of the Industrial Network module.
 Ethernet-based networks have additional link and activity lights located on the RJ-45
connectors.
LED NS – Network Status
STATE
STATUS
Green
Online, connection(s) established
Green, flashing
Online, no connections established
Red
Duplicate IP address/Critical link failure
Red, flashing
Connection(s) timed out
Off
No power or no IP address
LED MS – Module Status
STATE
STATUS
Green
Controlled by Scanner in Run state
Green, flashing
Not configured or Scanner in Idle state
Red
Major fault
Red, flashing
Recoverable fault
Off
No power
