LaserMech FiberMINI 2.0 - Specifications

PLMNL0286 REV. B, Effective Date: 06/06/19 43 FiberMINI
®
with Auto Focus (AF) Operation Manual
6 Specifications
CUTTING HEAD
Power Rating ............................................................................................................ 4 kW CW, 10 kW Peak
Focusing Lens (Effective Focal Length) ........................................... 100 mm*, 125 mm, 150 mm, 200 mm
................................................................................... * Air blast is NOT available with 100 mm EFL model
................................................ * Focal point to nozzle adjustment range is shifted for 100 mm EFL model
Focusing Lens (Diameter) ................................................................................................................. 28 mm
Clear Aperture ................................................................................................................................... 25 mm
Assist Gas Pressure ............................................................................................................... up to 20 BAR
Air Cooling Pressure .................................................................................... 2.0 – 3.5 Bar (30.0 – 50.0 psi)
Water Pressure ................................................................................................ 5.0 Bar Max (72.5 psi max)
Water Flow ................................................................................................................................ 1.5 L/minute
Focal Point to Nozzle Adjustment ................................................................................ +4.5 mm to -9.5 mm
Focal Point to Nozzle Adjustment (100 mm* EFL model ONLY) ................................. +7.5 mm to -6.5 mm
Lens Positioning Repeatability Accuracy .................................................................................. +/-0.05mm
Weight ...................................................................................................................................... 1.5 to 4.0 kg
LASER MECH COLLIMATOR
Effective Focal Length (Doublet, Fused Silica) ..................................................... 60 mm, 75 mm, 100 mm
Collimating Lens (Diameter).............................................................................................................. 28 mm
Clear Aperture ................................................................................................................................... 25 mm
Fiber Socket (Others Available On Request) ....................................................................................... QBH
HEIGHT SENSOR
Standoff Distance Range (1 mm recommended)............................................................ 0.2 mm to 8.0 mm
Calibration .............................................................................................. Single Point Calibrating at 12 mm
Response Time .............................................................................................................................. <1 msec
Temperature Stability .......................................................................... ±5% of Standoff Setting, 0° to 45°C
Power Requirement ...................................................................................................................... +24 VDC
Output .................................................................................................................................... 0-10 V Analog
See Interface Signals .................................................................................................................. Section 3.4
Specifications are subject to change without notice.
