LaserMech FiberMINI 2.0 - Troubleshooting

PLMNL0286 REV. B, Effective Date: 06/06/19 44 FiberMINI
®
with Auto Focus (AF) Operation Manual
7 Troubleshooting
SYMPTOM
CAUSE
REMEDY
HSU Fault:
1: Tip Open
There is no connection between the HSU
and tip assembly during calibration.
Verify the tip assembly and
internal sense cables are properly
installed and then recalibrate.
See Section 3.8 for the calibration
procedure.
HSU Fault:
2: Tip Shorted
The tip is not fully insulated from ground
and the body of the cutting head during
calibration.
Remove any debris that may be
causing a short and then
recalibrate.
See Section 3.8 for the calibration
procedure.
HSU Fault:
3: Cable Break
The connection between the HSU and tip
has been broken.
Verify the tip assembly and tip are
properly installed and then
recalibrate.
See Section 3.8 for the calibration
procedure.
Position Fault
The lens was out of the commanded
position for an excessive amount of time or
encountered unusual resistance while
attempting to move.
Activate the Reset bit or button to
re-enable the servo.
Temperature Fault
The temperature of one or more sensors
has exceeded the limit.
Allow the component to cool.
Consider raising the temperature
limit if it is safe.
Inspect the optics, verify tip
centering and focus position.
