LaserMech FiberMINI 2.0 - Recommended Parts List

PLMNL0286 REV. B, Effective Date: 06/06/19 45 FiberMINI
®
with Auto Focus (AF) Operation Manual
8 Recommended User-Serviceable Parts List
For recommended user-serviceable spare parts, please call Laser Mechanisms at (248) 474-9480. If your
head requires service beyond the instructions outlined in this manual, please contact Laser Mechanisms for
further assistance.
ITEM
PART #
DESCRIPTION
CABLES
1
PLCAB0608
Control Cable (Twisted Pair Cable, 8 m Long)
2
PLCAB0701
Control Cable (Twisted Pair Cable, 20 m Long)
3
PLTTW0003
Tip Transformer Wire for Height Sensing
FIBER INTERFACE ADAPTER
4
PLFIA0054
Water Cooled QBH Fiber Interface Assembly for FiberMINI
®
AF
60 mm Recol, 0.175 NA Optical Black (Complete Assembly)
5
PLFIA0053
Water Cooled QBH Fiber Interface Assembly for FiberMINI
®
AF
75 mm Recol, 0.14 NA Optical Black (Complete Assembly)
6
PLFIA0052
Water Cooled QBH Fiber Interface Assembly for FiberMINI
®
AF
100 mm Recol, 0.11 NA Optical Black (Complete Assembly)
7
PLFTG0104
G1/8 Male Elbow Fitting for 6mm OD Tubing
(Included in PLFIA0054, PLFIA0053 and PLFIA0052)
FOCUS LENS CARTRIDGE
8
PLFLH0527
Symmetrical Doublet Focus Lens Assembly for FiberMINI
®
AF
100 mm Focus Length (Complete Assembly)
9
PLFLH0522
Symmetrical Doublet Focus Lens Assembly for FiberMINI
®
AF
125 mm Focus Length (Complete Assembly)
10
PLFLH0528
Symmetrical Doublet Focus Lens Assembly for FiberMINI
®
AF
150 mm Focus Length (Complete Assembly)
11
PLFLH0532
Symmetrical Doublet Focus Lens Assembly for FiberMINI
®
AF
200 mm Focus Length (Complete Assembly)
COLLIMATORS
12
PLFRA0144
Collimator Assembly for FiberMINI
®
AF – 60 mm (Complete Assembly)
13
PLFRA0145
Collimator Assembly for FiberMINI
®
AF – 75 mm (Complete Assembly)
14
PLFRA0146
Collimator Assembly for FiberMINI
®
AF – 100 mm (Complete Assembly)
COVER GLASS
15
PLFLH0409
Cover Glass Holder
16
PLLCG0034
Cover Glass
17
PLMSR0014
Manifold Seal Ring (Included in PLFLH0409)
FITTINGS
7
PLFTG0104
G1/8 Male Elbow Fitting for 6mm OD Tubing
18
PLFTG0126
G1/8 Male Swivel Fitting for 6mm OD Tubing
AIR BLAST NOZZLE
19
PLCFJ0040
Air Blast Nozzle Assembly – 125 mm Focus Length (Complete Assembly)
20
PLCFJ0043
Air Blast Nozzle Assembly – Extra Fitting (Complete Assembly)
Not Shown
21
PLCFJ0047
Air Blast Nozzle Assembly – 150 mm Focus Length (Complete Assembly)
Not Shown
22
PLTUC0007
Air Blast Nozzle (Included in PLCFJ0040 and PLCFJ0043)
23
PLTUC0001
Air Blast Nozzle (Included in PLCFJ0047 ONLY)
