PLMNL0286 REV. B, Effective Date: 06/06/19 17 FiberMINI
®
with Auto Focus (AF) Operation Manual
Control Options (In 14 / Web 3.5 / 21.5)
BIT 7
BIT 6
BIT 5
BIT 4
BIT 3
BIT 2
BIT 1
BIT 0
Reserved For Future Use
Enable
Step/Dir
Invert
Direction
Maintain
Ready
IN POS
Function
IN POS Function: 0 = In Position, 1 = At Home.
Command Bits (Out 0 / Web 11)
BIT 7
BIT 6
BIT 5
BIT 4
BIT 3
BIT 2
BIT 1
BIT 0
Reserved For Future Use
Calibrate
Move
Lens
Reset
Servo
Clear
Historical
Faults
Web Interface (Ethernet based network only)
The web interface provides an alternate means to view sensor data and configure the interface when a
USB connection is not available.
From any web browser on the same network, enter the IP address assigned to the Network Interface
box.
If you are unsure of the current IP address, retrieve it using the Industrial Network Configuration
screen in FiberMINI
®
Monitor (see Section 4.5.6).
The Module Parameters screen displays a snapshot of sensor values, limits, and device identifying
information.
Reference the WEB ID column of the data map for a description of available data.
To change a sensor limit or command bit:
o Click on the text box in sections 11, 21 or 22.
o Enter the desired value using the unit formatting noted above.
o Click Set.
Click Refresh to update all values or cancel setting.
Refer to Figure 17.
