Lattice Semiconductor MachXO2 User Manual

MachXO2 and MachXO3 Starter Kit Evaluation Board User Guide
Evaluation Board User Guide
© 2014-2022 Lattice Semiconductor Corp. All Lattice trademarks, registered trademarks, patents, and disclaimers are as listed at www.latticesemi.com/legal.
All other brand or product names are trademarks or registered trademarks of their respective holders. The specifications and information herein are subject to change without notice.
14 FPGA-EB-02036-1.4
Table 6.2. DIP Switch and LED Behavior
Switch
Setting
LED Behavior
DIP_SW[1]
0 (Down)
External 12.0 MHz (X1)
1 (Up)
Internal 12.09 MHz (OSCH)
DIP_SW[2:4]
001
1 Hz Sweep
011
1 Hz Left-Right
111
1 Hz Blink
Others
1 Hz Alternating
WARNING: Do not connect the board to your PC before you follow the driver installation procedure of this section.
Communication between the board and a PC, through the USB connection cable, requires installation of the FTDI chip
USB hardware drivers. Loading these drivers enables the computer to recognize and program the board. Drivers can be
loaded as part of the installation of Lattice Diamond design software or Diamond Programmer, or as a stand-alone
package.
