Lattice Semiconductor MachXO2 User Manual

MachXO2 and MachXO3 Starter Kit Evaluation Board User Guide
Evaluation Board User Guide
© 2014-2022 Lattice Semiconductor Corp. All Lattice trademarks, registered trademarks, patents, and disclaimers are as listed at www.latticesemi.com/legal.
All other brand or product names are trademarks or registered trademarks of their respective holders. The specifications and information herein are subject to change without notice.
18 FPGA-EB-02036-1.4
Table 7.2. Expansion Header Pin Information (J3)
Header Pin Number
-4000 Function
-6900C Function
MachXO2/MachXO3 Ball
1
VCCIO0
VCCIO0
D5,D12,G8,G9
2
VCCIO0
VCCIO0
D5,D12,G8,G9
3
PT28C/INITn
PT36C/INITn
A13
4
PT28D/DONE
PT36D/DONE
C13
5
PT20A
PT22A
F8
6
PT27B
PT35B
B12
7
PT27A
PT35A
C12
8
PT22B
PT26B
E11
9
PT23B
PT27B
E10
10
PT23A
PT27A
D10
11
GND
GND
—
12
GND
GND
—
13
PT22A
PT26A
F9
14
PT23C/JTAGENB
PT27C/JTAGENB
C10
15
PT15B
PT17B
E8
16
PT19B
PT21B
E9
17
PT13B
PT14B
E7
18
PT19A
PT21A
D8
19
PT14D
PT16B
D7
20
PT14B
PT15B
C7
21
GND
GND
—
22
GND
GND
—
23
PT10B
PT10B
C5
24
PT13A
PT14A
D6
25
PT14C
PT16A
E6
26
PT9A
PT9A
C4
27
PT21B
PT25B
A10
28
PT15A
PT17A
F7
29
PT20B
PT22B
D9
30
PT21A
PT25A
B9
31
GND
GND
—
32
GND
GND
—
33
PT11B
PT11B
B6
34
PT14A
PT15A
B7
35
PT9B
PT9B
B5
36
PT11A
PT11A
A5
37
PT12B
PT12B
B4
38
PT10A
PT10A
A4
39
GND
GND
—
40
PT12A
PT12A
A3
