Lattice Semiconductor MachXO2 User Manual

MachXO2 and MachXO3 Starter Kit Evaluation Board User Guide
Evaluation Board User Guide
© 2014-2022 Lattice Semiconductor Corp. All Lattice trademarks, registered trademarks, patents, and disclaimers are as listed at www.latticesemi.com/legal.
All other brand or product names are trademarks or registered trademarks of their respective holders. The specifications and information herein are subject to change without notice.
38 FPGA-EB-02036-1.4
Item
Quantity
Reference
Value
Manufacturer
MFG Pin
29
16
R46, R47, R48, R49, R50, R51, R52, R53, R54, R55, R56,
R57, R58, R59, R60, R61
RC0402FR07100RL
30
2
R87, R88
49.9
Vishay
CRCW060349R9FKEA
31
2
R89, R90
Vishay
CRCW0603150RJNEA
32
1
SW1
E-Switch
TL1015AF160QG
33
1
SW2
CTS Electrocomponents
195-4MST
35
1
U1
FT2232HL
36
1
U2
Microchip
93LC56C-I/SN
37
1
U3
Fairchild Semi
FAN1112SX
38
1
U4
On Semi
NCP1117ST33T3G
39
1
U5
Lattice Semiconductor
LCMXO2-4000ZE-1BG256C,
LCMXO3L-6900C-
5BG256C, or LCMXO3LF-
6900C-5BG256C
40
1
U6
Spansion, On Semi
S25FL204K0TMFI041 (early
builds) or
S25FL208K0RMFI041 (later
builds), LE25U40CMDTWG
(later builds)
41
1
X1
12 MHz
TXC
7M-12.000MAAJ-T
