LAUNCH X-431Diagun User's Manual
4
1 X-431Diagun
main unit
Main unit screen contains
operation buttons, test
result and help.
2 X-431Diagun
connector
Diagnostic box with
OBDⅡ-16 pin connector
3 X-431Diagun
main unit
diagnostic cable
to connect X-431Diagun
main unit and
X-431Diagun connector
4 Diagnostic
adaptor
16 PIN extension cable
for X-431Diagun
connector
5 Stylus for clicking operation on
X-431Diagun
6 Battery Charger
for main unit charge by
transforming AC
100-240V to DC 5V
7 TF card to store diagnostic
program and data
8 TF card reader to read and store data,
and for online update
when connected to PC
9 USB cable connect X-431Diagun
main unit to PC, and for
online update by wire
connection
10 Printer cable connect X-431Diagun
main unit to the printer
11 non-16PIN
diagnostic
connector
(Several)
Diagnostic connector for
special models (Optional)
(Optional)
