LAUNCH X-431Diagun User's Manual
2
2 X-431Diagun
2.1 X-431Diagun Component Descriptions
X-431Diagun includes: X-431Diagun main unit(right) and X-431Diagun
connector(left)-see fig.2-1. X-431Diagun main unit communicates with
X-431Diagun connector via wireless Blue Tooth (also supports wire
connection).
Figure 2-1X-431Diagun External View
2.2 Port and Indicator Descriptions
Figure 2-2 is for each port and indicator of X-431Diagun:
