LAUNCH X-431Diagun User's Manual
8
2.6 Battery and Charger
2.6.1 Battery
Your appliance is powered by a rechargeable lithium battery. The followings,
such as crush the battery, short-circuit the battery, dispose of the battery in a
fire or in the high temperature environment and dispose as household waste
etc, are prohibited. The warranty period of battery is 6 months.
2.6.2 Recharging Method
Two options to recharge X-431Diagun: one is to use the charger (see the
No.6 of Diagram 2-2 in chapter 2.3 for details); the other is to use an
external power supply (DLC) via wire connection.
2.6.3 Description of the Power Indicator State
Recharge through the charger
Recharge it under conditions of power off, power on and stand-by mode.
The power indicator (green light) stays on when recharging and off when the
battery is fully recharged.
Note: It is better to charge in stand-by mode for charging saturation.
(How to set ‘standby’: click the start menu "
" , a dialogue box will
be popped up, click "Suspend", or press the power key on the main
unit; press the power key again to resume the normal state and actuate
the screen)
Recharge through DLC
Recharge it under conditions of power off, power on and stand-by mode.
The power indicator (green light) always on when charging and off when the
battery is fully recharged.
2.6.4 Description of the Battery State
1. The appliance could be turned on either being connected to the charger
or an external power supply. "
” icon would then appear in the taskbar,
Power Properties interface shows ‘charging’, as shown below:
