Figure 2-2 X-431Diagun main unit ports and indicators
Diagram 2-1 X-431Diagun ports and indicators
A
Diagnostic Connector B Diagun Connector
C Blue Tooth LED (blue) D Power LED (red)
E 12PIN Port F Lanyard Eyelet
G Diagnostic Interface H Earphone Hole & TF Card Slot
I Power Button J Diagun Main
K Touch Screen L Stylus Holder
M Main Back N Buzzer
O Reset Button P Battery Cover
2.3 X-431Diagun General Components
Diagram 2-2 is for each component
No. Name Description Picture

Launch X-431 Diagun Specifications

General

Brand	Launch
Model	X-431 Diagun
Category	Diagnostic Equipment
Language	English
