LAUNCH X-431Diagun User's Manual
15
3.2.1 Diagnostic Program
After connecting X-431Diagun (see
chapter 3.1.3 for details), turn it on and
press ‘
’ button at the top right corner of
the main unit to enter into calibration
interface (see chapter 2.5.2). After that,
with the Wince interface displayed,
double click the icon "Blue Tooth
(wireless)" on the desktop to operate
X-431Diagun, as shown in the left figure.
Vehicle Make interface will appear as
shown on the left.
Button Descriptions:
[RETURN]: return back to the previous
interface.
[PREVPAGE]: show the previous page.
This button is invalid and in gray if there
is only one page or the first page
currently.
[NEXTPAGE]: show the next page. This
button is invalid and in gray if there is
only one page or the last page currently.
[HISTORY]: view driving management
record (the recorded datastream and
waveform).
[SETTING]: select language.
