LAVAZZA LB 2302 - Machine Range and Configurations

WITH STEAM
1.2.7. Range
4
Manual code 10083445 / Rel. 0.00 / April 2010
Maintenance manual for technical assistance LB 2300-2301-2302-2311-2312
Dispensing spout for 2 products (C)
Steam/hot water pipe
Dispensing spout for 1 product (B)
Steam/hot water pipe
Dispensing spout for 1 product (A)
DOUBLE CUP
WITH STEAM
SINGLE CUP
WITH STEAM
A
B
C
LB 2300 Cap 01
SINGLE CUP
