11.17. Perforator filter disassembly
Remove the brew unit.
Loosen the indicated screws.
PU
S
H
Loosen the indicated screws.
PU
S
H
58
Manual code 10083445 / Rel. 0.00 / April 2010
Maintenance manual for technical assistance LB 2300-2301-2302-2311-2312
