Manual code 10083445 / Rel. 0.00 / April 2010
Maintenance manual for technical assistance LB 2300-2301-2302-2311-2312
5
1.2.8. Machine identification data
In the plate the following identification data of the
m
achine are indicated:
1.2.9. Technical specifications
Power supply voltage:
230 V~, 50 Hz
120 V~, 60 Hz
Power
Total: 1570 W
1100 W Coffee/hot water dispensing
470 W Additional for steam dispensing
Safety system:
Thermostat
Water level sensor:
Capacitive sensor
Pump:
Ulka brand with alternate piston and thermal
protector 100°C
48 W, 230V, 50 Hz, Type EP5 ca. 13-15 bar
Pressure relief valve:
Opens at 13-14 bar about
Water filter:
In the tank
Consumption:
During heating phase- about 6,8 A
Weight:
10,5 kg
Water tank capacity:
4 litres
Capsule container capacity:
Max. 20
-
Manufacturer;
- Machine name;
- Serial number;
- Power supply voltage (V) and frequency (Hz);
- Power consumption (W);
- Water mains pressure (MPa).
Note
In case of contact with authorized service centres,
please indicate the model and serial number.
391
327
473
O
perating conditions:
Minimum temperature: 10°C
Maximum temperature: below 40°
M
aximum humidity: below 95%
Brewing temperature:
about 73°C - 83°C
1.2.10. Overall dimensions
Deep: 473 mm
Width: 327 mm
Height: 391 mm
1.2.11. List of the accessories supplied with
the machine
Booklet: Instructions for using the
machine.
Water hardness test: Quick test to determine the har-
dness of the water used to pre-
pare beverages; this is a very
important test to set the har-
dness of the water used by the
machine.
Key for water tank access: prevents
access to water tank by unauthorised per-
sonnel.
BRITA INTENZA filter
