11.22. Assembly and removal of the OETIKER clamps
To tighten the clamp use the proper pliers.
Check the correct clamping (A) and positioning.
To remove the clamp use the pincers as indicated in
the figure (B).
A
B
66
Manual code 10083445 / Rel. 0.00 / April 2010
Maintenance manual for technical assistance LB 2300-2301-2302-2311-2312
