LAVAZZA LB 2302 - Steam Pipe Disassembly; Steam Solenoid Valve Disassembly

11.5. Steam pipe disassembly
Disassemble the steam pipe by using a spanner.
11.6. Steam solenoid valve disassembly
Disconnect the faston, loosen the nut and remove the
coil.
Remove the steam pipe.
44
Manual code 10083445 / Rel. 0.00 / April 2010
Maintenance manual for technical assistance LB 2300-2301-2302-2311-2312
