I
n this case it is possible to reach the microswitch that
controls if the capsule loading tray is open.
To remove the microswitch lightly widen the two stops
and lift it up.
The unit can be checked by removing it from its seat
as indicated in the figure.
51
Manual code 10083445 / Rel. 0.00 / April 2010
Maintenance manual for technical assistance LB 2300-2301-2302-2311-2312
