6300 Rev H User’s Manual
125-9106A Page 27
Figure 3.10 : Jog the Static Target value
In this screen, the Upper section has a new symbol (with Up & Down arrows) to the right of the Static
Target value field. This indicates that the Static Target value can be jogged up or down repeatedly, in
steps of 1 foot, using the Arrow keys, until CANC is pressed. In this case, since the Up-Arrow key was
pressed, the Static Target value was incremented to 1 foot. Press Up-Arrow one more time and the value
will change to 2. Press Down-Arrow two times and the value decrements to 0.
Note: It is not possible to Jog a Target value if it is blinking.
The incremental value for the Jog feature varies depending on Static units and is shown in the table
below.
Static units Jog increment
Feet 1
Meters 1.0
inHg 0.001
mbar 0.01
psi 0.001
mmHg 0.01
kpa 0.001
3.5 CHANGING RATE TARGET VALUES
Note: Rate-Target values are maintained through a power OFF/ON cycle.
