SECTION 4 : PROFILES
Profiles are created in Microsoft Excel and loaded into the 6300 through the COM1 port on your PC using
the Hyperterminal program that is normally available on all PC’s.
4.1 WHAT IS A PROFILE
A profile is a set of up to 50 points that tell the 6300 what you would want it to do at each point. Each
point consists of 8 parameters: 1) Pitot units, 2) Pitot mode, 3) Pitot target value, 4) Pitot Rate target
value, 5) Static units, 6) Static mode, 7) Static target value and 8) Static Rate target value. These 8
parameters are defined by you in the Excel program.
A total of 15 such profiles can reside in the 6300 at any time. Each profile is identified by a number
between 1 to 15 and also a name which can have up to 12 characters. The profile number and the name
are also part of the profile that is created in Excel.
A typical profile named “Sample” is shown below as it would appear in Excel.
A B C D E F G
H
1 Profile
2 Sample
0
3 knots Control 100.0 150.0 Feet Control 0 6000
4 knots Control 200.0 150.0 Feet Control 0 6000
5 knots Leak 200.0 150.0 Feet Control 0 6000
6 knots Control 100.0 150.0 Feet Control 1000 6000
7 knots Control 200.0 150.0 Feet Control 5000 6000
8 knots Control 300.0 150.0 Feet Control 10000 6000
9 knots Control 100.0 150.0 Feet Control 18000 6000
10 knots Control 100.0 150.0 Feet Leak 18000 6000
11 knots Control 100.0 150.0 Feet Control 30000 6000
12 knots Control 100.0 150.0 Feet Control 50000 6000
13 knots Control 20.0 150.0 Feet Control Ground 6000
14 knots Measure 20.0 150.0 Feet Measure Ground 6000
15 END
Row 1 always says “Profile”. This indicates to the 6300 that a profile is to follow.
Row 2 left cell shows the name of the profile. This profile is named “Sample”. The name can have up to
12 alphanumeric characters. This name will be displayed on the Remote unit when this particular profile
is Run.
Row 2 middle cell shows the number of the profile. This profile has a number 3. This tells the 6300 that
this profile is to be loaded in as profile number 3. When profile 3 is Run on the 6300, this “Sample”
profile will be executed. This number can be any number between 1 and 15. When this profile is loaded
into the 6300 it will overwrite the previous profile that was resident in the 6300 as number 3.
