Leetro MPC6575 User Manual

Develop HMI
31
z Addresses and functionalities of PLC register are as shown in following table:
Refer to the following descriptions on each bit (Address: 32):
Data length
Address
Device
Type
Data
Type
bit byte
Functionality
1 4x BIN 16 1 Percentage o f processing speed (%)
2 4x BIN 16 1 Laser power corresponding to high
speed
3 4x BIN 16 1 Laser power corresponding to low speed
4 4x BIN 16 1 Set the pieces to be processed
5 4x BIN 16 1 Reserve
6 4x BIN 16 1 Completed pieces
7 4x BIN 16 1 Reserve
8 4x BIN 32 2 Shooting time:low
16 bit
9 Shooting time:high
16 bit
Shooting time
unit: Millisecond
10 4x BIN 16 1 Jogging distance
11 4x BIN 16 1 Reserve
12 4x BIN 16 1 Reserve
13 4x BIN 16 1 Shooting time
14 4x BIN 16 1 Shooting power
15 4x BIN 16 1 Total number of files downloaded to the
controller
16 4x BIN 16 1 Current File No.
17 4x 64 4 File name (abcdefgh, 8 bytes shown in
text mode)
21~28 4x BIN 16 1 Reserve
29 4x BIN 16 1 Processing time (h)
30 4x BIN 16 1 Processing time (m)
31 4x BIN 16 1 Processing time (s)
32 4x BIN 16 1 Working status
33 4x BIN 16 1 Download progress (with USB stick) (%)
