PAD03 Operation
9
Press Laser to beam according to the settings of LASER SET.
Press Datum to have the X-axis and Y-axis make homing motion simultaneously;
X and Y axes will not stop until they reach the origin point or the user press Stop button.
Press Test to generate the contouring motion, and following text displays.
When bordering finished, press to return to the main interface.
Press Z button, text displays as follows:
Press or to generate Z-axis jogging.
Press Datume to make Z-axis do homing motion.
Press Stop to stop the homing motion of Z-axis.
Press Z to return to the main interface.
Text displayed when Z-axis is homing.
Z axis will not stop until it reaches the origin point or the user press Stop button.
5.5 Supporting Interface
Press Menu to enter the supporting interface as follows.
Z-AXIS DATUM
Z-AXIS OPERATE
BORDERING
PLEASE WAIT
DATUM…
