Leetro MPC6575 User Manual

MPC6575-Close-loop Laser Engraving &Cutting Controller (Rev. 1.0)
32
F E D C B A 9 8
1:
Speed-zero
clamp
0: Cancel
speed-zero
clamp
1: In pausing
0: Paused
1: In
jogging
0: Jog
stops
7 6 5 4 3 2 1 0
1: Start
download
0:
Download
completed
1: plug in
the USB
stick
0: pull out
the USB
stick
1:
Z-axis
datum
0: Stop
1:
Datum
0: Stop
1: Cut
Border
0: Finished
1: Bordering
0: Finished
1: Start
0: Stop
1:
Pause
0:
Resume
Status Code
0x0002: is processing
0x0003: processing is paused
0x0004: bordering
0x0008: cut border
0x0010: XY axes is homing (Datum)
0x0020: Z axis is homing (Datum)
0x0040: USB stick is detected
0x00c0: is downloading data from USB stick
0x0080: download completes, USB stick can be removed
0x0100: jogging
Remark: Each value of the status register indicates a special status.
8.3 Demo
Demonstration programs used for HMIs such as MT506LV45WV and BYD037L can be found in
the software kit. User can refer to the demonstration programs to develop HMIs.
