Whole House Lighting Controller - LC7001 1308243 REV. F
15
Google Home Voice Control Integration
Prerequisites
Enabling voice control of the Legrand Lighting Control System through Google Home requires
the following:
• a Google Home device
• the Legrand Whole House Lighting Controller (LC7001)
• the latest version of the Google Home app
• the latest version of the Google app (Android only)
• a Google account
• an Internet connection
• the Legrand Lighting Control app, version 4.0 or newer
• an active Legrand cloud account integrated with the user’s Legrand Whole House Lighting
Controller (LC7001).
NOTE:
For instruction on creating and integrating a Legrand cloud account with the LC7001,
refer to “Setting up Remote Access” in the Legrand Whole House Lighting Controller User Guide
or go to Settings > Remote Access Info > Remote Access Setup in the Legrand Lighting
Control app.
Connecting Google Home to the Legrand Lighting Control
System
1. Open the Google Home app.
2. Select Add.
3. Select Set up device.
