Signal Processing
Balanced inputs (IN A & IN B).
20-bit A/D converters.
LED ladders for monitoring input signals.
5-band parametric equalizers for A & B inputs.
3 delay lines (IN A, IN B & Sum A+B).
Routing System for connecting INPUTS and OUTPUTS.
Delay lines in 1-4 output.
Low-pass filters (LPF) with phase fine control - CROSSOVER.
High-pass filters (HPF) - CROSSOVER.
5-band parametric equalizers for the outputs.
Output level controls.
Polarity inverter.
Output level LIMITERS.
LED ladders showing output levels and limiter action.
Output MUTING controls.
24-bit D/A converters.
XLR-M balanced outputs.
